DC DC Converter 12V TO 24V 1A-30A Step-up Boost Converter Power Module Step-Up CE RoHS for Cars
WHY CHOOSE US
- low price
- stable performance
- safety, reliability
- long service life
Description
DC DC Converter 12V TO 24V 1A-30A Step-up Boost Converter Power Module Step-Up CE RoHS for Cars
Boost Voltage Converter 12V to 24V 30A 25A 20A 15A 12A 10A 8A 5A 3A 2A 1A Power Module DC-DC Step Up CE RoHS for Cars
FEATURES
*Design meeting RoHS/CE
*100% full stable current output
*Non-isolated between input and output
*Internal capacitor: NCC& NICHICON(high reliability)
*100% full load burn-in test
*Waterproof level IP68
*Die-cast aluminum shell or Aluminum shell with Oxidation Resistant Coatings to avoid rust, epoxy potting
*Cooling by free air convection
*Surface mountable
*Over-current, low-voltage, and over-temperature protections
FEATURES
*Design meeting RoHS/CE
*100% full stable current output
*Non-isolated between input and output
*Internal capacitor: NCC& NICHICON(high reliability)
*100% full load burn-in test
*Waterproof level IP68
*Die-cast aluminum shell or Aluminum shell with Oxidation Resistant Coatings to avoid rust, epoxy potting
*Cooling by free air convection
*Surface mountable
*Over-current, low-voltage, and over-temperature protections
Notes:
Please connect the polarity correctly, or the converter will be burnt.
This DC/DC Converter can’t work as a solar or wind controller.
Additional information
| Ships From | undefined |
|---|---|
| Color | 12V to 24V 1A, 12V to 24V 2A, 12V to 24V 3A, 12V to 24V 5A, 12V to 24V 8A, 12V to 24V 10A, 12V to 24V 12A, 12V to 24V 15A, 12V to 24V 20A, 12V to 24V 25A, 12V to 24V 30A |
| Input Voltage | 12V |
| Output voltage | 24VDC |
| is_customized | Yes |
| Output Current | 1A, 2A, 3A, 5A, 8A, 10A, 12A, 15A, 20A, 25A, 30A |
| Output Frequency | DC/DC Converters |
| Weight | 110g, 300g, 500g, 1.5kg |
| Output Type | single |
| Output Power | 1 – 200KW |
| Model Number | 12V to 24V Car Power Converter |
| Type | Non-isolated module |
| Brand Name | kangwobei |
| Origin | Mainland China |
| Certification | CE, FCC, RoHS, UL, pse |
| Size | 64*57*22mm, 74*74*32mm, 100*80*39mm….. |
| Input rated voltage | 12VDC |
| Output peak power | 135% |
| Efficiency | up to 96% |
| Voltage regulation | < 1% |
| Load regulationg | < 2% |
| Cooling way | Free air convection |
| Waterproof | YES |
| Dustproof | YES |
| Warranty | 1 year |
| Applications | Cars, Boats, LED, Solar Wind System and so on. |
